Arduino Lesson 01: Getting Started
Arduino Lesson 1

Arduino Setup

This tutorial will guide you on how to setup Magicbit with Arduino IDE

Components Required

Buy Now

What is Arduino?

The Arduino Integrated Development Environment is a cross-platform application that is written in functions of C and C++. It is used to write and upload programs to Arduino compatible boards. But also, with the help of third-party cores, other vendor development boards.

Learn About Arduino Download Arduino

Install Magicbit



Magicbit is based on ESP32 and Arduino core because Magicbit is forked from the espressif/arduino-esp32. Therefore, to program a Magicbit with the Arduino IDE, you will have to go through the following steps.

  • Release Link –https://github.com/magicbitlk/arduino-esp32/releases/download/Magicbit/package_magicbit_index.json

  • ( for macos use this link : https://raw.githubusercontent.com/espressif/arduino-esp32/gh-pages/package_esp32_dev_index.json)

  • Install the current Arduino IDE at the 1.8 level or later.
  • Start Arduino and open the Preferences window.
  • Enter the release link above into the Additional Board Manager URLs field. You can add multiple URLs, separating them with commas.
  • Open Boards Manager from Tools > Board menu and install Magicbit platform (and don’t forget to – – select Magicbit from Tools > Board menu after installation).

Powering Up



Magicbit can be power up by either connecting a USB cable or connecting a battery. For programming, a USB cable must be connected to the computer. For the first time powering up the Magicbit self-test program will be running on the Magicbit and you can see the features available and functional tests on the Magicbit display.

To check whether drivers are correctly installed, open the Arduino IDE and go to the Tools menu. There should be a port (Eg: COM1) shown when plugging Magicbit into the computer, as shown below. If not please follow the Installation drivers section.

Installation Drivers

Magicbit has a CH340 chip as a USB-Serial converter which the driver is already packaged with Arduino IDE. If the port is not shown in the Arduino as shown below, please install the driver from the Magicbit utility.

Your First Project…

  • Open Arduino IDE if not opened already
  • Select Magicbit from Tools ⇒ Boards
  • Select port Tools ⇒ Ports
  • Open Blink Example File ⇒ Examples ⇒ Basic ⇒ Blink
  • Upload the code to the Magicbit using the upload button on Arduino IDE
  • If the Green LED on the backside of the Magicbit is blinking, you have just begun the magic with Magicbit

I am text block. Click edit button to change this text. Lorem ipsum dolor sit amet, consectetur adipiscing elit. Ut elit tellus, luctus nec ullamcorper mattis, pulvinar dapibus leo.

I am text block. Click edit button to change this text. Lorem ipsum dolor sit amet, consectetur adipiscing elit. Ut elit tellus, luctus nec ullamcorper mattis, pulvinar dapibus leo.

If you get this error set Upload Speed to 115200 from Tools menu and try again

Automatic uploading may not work properly in some computers. Try following steps if you get Connecting… message on output window in Umagicbit uploader or in Arduino

  1. Press flash button on Magicbit before click upload
  2. Press and release reset button while holding the flash button down
  3. Release the flash button

magicbit uploading issue

Then try to upload again.
