Arduino Lesson 07: Generating Tones
Arduino Lesson 7

Generating Tones

Generate tones from the buzzer

Components Required

Buy

Introduction

In this example, you are learning to generate a tone using the onboard buzzer on the Magicbit.

Learning Outcomes

From this example, you’ll get an understanding about,
  • Tone Function

Theory

Piezo buzzers are commonly used in embedded systems to give audible tones. Combined with ESPservo library, Magicbit can generate various tones.

Methodology

For this example, we use the piezo buzzer wired to pin 25 of the Magicbit.



Magicbit buzzer































ESP32Servo.h library is used to generate PWM signals needed to generate tones. We could specify the frequency & duration of the tone.

.

Code


#include <ESP32Servo.h>
void Setup(){
   pinMode(25,OUTPUT);
}
void loop(){
   tone( 25 ,4186,500); //C Note
   delay(1000);
   tone( 25,5274,500); //E Note
   delay(1000);
}

Explanation

tone(pin No, frequency, duration): generates PWM to corresponding to the given parameters

Activity

Note:: Create a program that plays one frequency when one push button on the board is pressed, and another frequency when the other push-button when pressed.
